30 Series Pressure Calibrator

Calibration tool box in the palm of your hand!

The 30 Series is a wide range digital pressure calibrator that fits easily into your shirt pocket. Its internal sensors give you 0.05% of reading accuracy and resist damage from overpressure.

Wide pressure range can measure vacuum and pressure up to 5000 psi (300 bar)
Indicates milliamps to calibrate transmitters
Ultra compact and light
Very easy to learn and use
Battery operated
Brings laboratory accuracy to outdoor field conditions

• Documentation

  • Brochure (4)

    • 30 Series Brochure
    • AMETEK Calibration Brochure
    • Pressure Selection Guide
    • Complete Pressure System Brochure

  • Datasheets (4)

    • 30 Series Datasheet, psi
    • 30 Series Datasheet, bar
    • 30 Series Datasheet, kPa
    • CPF Datasheet

  • Manuals (3)

    • 30 Series Manual
    • 30 Series ConFig30 Manual
    • 30 Series Programming Manual

  • Drawings (7)

    • 30 Series Product Drawing, IS31
    • 30 Series Product Drawing, IS33
    • T-1 Pump Connection Diagram
    • P-018 Pump Connection Diagram
    • T-620H Pump Connection Diagram
    • T-975 Pump Connection Diagram
    • GaugeCalHP Pump Connection Diagram

• Options

  • • -SPSS Stainless Steel Manifolds All high pressure sensors come with a stainless steel manifold. Some applications require that the second sensor be stainless steel as well.
  • • CrystalCare Crystal Care Program (US and Canada customers only) A 3-year full warranty program covering virtually any failure and an annual A2LA accredited calibration certificate with test data recorded at 5 different temperatures proving that it meets published specifications over the entire operating range.
  • • B Absolute Pressure Available for gauges rated at 2000 psi or higher. Add a B to the units to designate the absolute version (for example 2KPSIBXP2I).

  • System A

    • AHX Pump System: Includes a T-970 pneumatic hand pump (0 to 580 psi / 40 bar)
    • AXX Pump System: Includes a T-960 pneumatic hand pump (0 to 30 psi / 2 bar)

  • System B

    • BHX Pump System: Includes a T-975 pneumatic hand pump (-25 inHg to 580 psi / – 0.91 to 40 bar)
    • BXX Pump System: Includes a T-965 pneumatic hand pump (-25 inHg to 30 psi / – 0.91 to 2 bar)

  • System C

    • CHX Pump System: Includes a T-620H Hydraulic Hand Pump (0 to 5000 psi)
    • CXX Pump System: Includes a T-620 Hydraulic Hand Pump (0 to 3000 psi)

  • System D

    • DOX Pump System: Includes a P-018-CPF hydraulic screw pump (0 to 5000 psi, for use with oil)
    • DWX Pump System: Includes a P-018-CPF hydraulic screw pump (0 to 5000 psi, for use with water)

  • System E

    • EOX Pump System: Includes a P-014 hydraulic bench top pump (0 to 10 000 psi, for use with oil)

  • System F

    • FOV Pump System: Includes a T-1 hydraulic bench top pump (0 to 15 000 psi, for use with oil)
    • FWV Pump System: Includes a T-1 hydraulic bench top pump (0 to 15 000 psi, for use with water)

  • System G

    • GOX Pump System: Includes a GaugeCalHP hydraulic pressure comparator (0 to 15 000 psi, for use with oil)
    • GWX Pump System: Includes a GaugeCalHP hydraulic pressure comparator (0 to 15 000 psi, for use with water)

  • System H

    • HOX Pump System: Includes a T-975 Pneumatic Hand Pump (-25 inHg to 580 psi / – 0.91 to 40 bar) and a T-620H Hydraulic Hand Pump (0 to 5000 psi / 350 bar)

• Accessories

  • • 5203 Magnetic Hanging Strap for XP2i, m1, 30 Series, HPC40 Series, and HPC50 Series
  • • 3009 Hard Carrying Case egg crate foam. External Dimensions: 14 x 11 x 3.2 inches
  • • 2888 Weatherproof Hard Carrying Case die cut foam. Internal Dimensions: 16.8 11.2 6.1 inches
  • • 4431 USB A to Micro USB Cable for 30 Series (6ft)
  • • 1351 Test Lead Kit.

• Software

  • ConFigM30

    ConfiM30 (Free) Allows you to customize your calibrator by adding or disabling features

  • FastCalXP

    FastCalXP Calibration software that allows you to do a 10 point up and down calibration in less than 3 minutes.

  • USB Driver

    USB Driver for XP2i, nVision, and 30 Series

  • UnitCalc

    UnitCalc (Free) Easy pressure unit calculator. Displays all conversion factors and converted units at the same time. UnitCalc also calculates Head Correction, Gravity Correction, and Air Density
