Adjustable Angle Bimetal Thermometer

Reotemps Bimetal Thermometers are reliable and accurate temperature sensors requiring no electricity or wiring. This line of thermometers is designed for OEM applications in a variety of industrial applications where a more economical option is needed. Adjustable Angle Thermometers allow for easy temperature monitoring from any position and they are ideal for local indication. They can be recalibrated with a turn of the calibration screw on the back of the dial. A variety of options are available for your specific process needs.

• OEM Logo Dials/Custom Dials
• All Stainless Steel Construction
• Hermetically Sealed
• Silicone Fillable for Vibration
• Standard External Reset for Easy Calibration
• Dial can be adjusted to any position for easy viewing.
• One Year Warranty

Specifications

ACCURACY: 1.5% Full Scale DIAL SIZE: 3, 4 or 5 DIAL MATERIAL: White background with black marks.Anodized Aluminum background available. STEM LENGTH: 2 to 36 STEM DIAMETER: 1/4 HEAD, BEZEL, MOUNTING BUSHING, STEMS: 304SS BEZEL FINISH: Satin (std), High Gloss Mirror Finish available. OPERATING CONDITIONS: Head temperature should notexceed 200F (150F if silicone filled). Stem should not beexposed to continuous temperatures exceeding 50%over-range or 800F(550F if silicone filled). TEMPERATURE RANGES: See next page for complete list of ranges. CASE RATING: IP65, Hermetically Sealed LENS: Glass (std), Acrylic, Polycarbonate, Tempered Glass, Laminated Safety Glass IMMERSION: Minimum 2 in liquid, and 4 in gas for most ranges. Certain ranges require up to 4 in liquids & 5 in gas. MOUNTING CONNECTION: 1/2 NPT (std), 1/2 BSPT,1/4 NPT, 1/4 BSPP TEMPERATURE SENSING AREA: Last 2 to 4 of the stem NOTE: Thermowells should be used whenever the stem or bulb would be exposed to pressure, corrosion, velocity, abrasion or shear forces. Thermowells also make it possible to remove the thermometer without losing pressure or the contents of the process.

Data Sheet

Download Datasheet

Install Instructions

Download Install Instructions:

• Adjustable-Angle-Instructions-AATINST-0414 (PDF)
