Version:

• For gear measurement and for special tasks
• Carbide measuring balls
• Cylindrical mounting shank with circlip for mounting in the mounting bore of the micrometer or indicating snap gage

Description:

• Ball measuring insert, measuring contact ball diameter mm 3.2 mm , L = 15.5mm, = 3.5 mm

Feature:

• Calibration type: Uncalibrated
• Product group name: Marameter
• Product name: Ball measuring insert
• Material Measuring surface: Carbide
• Thread pitch in mm (proxy): false
• Thread pitch in TPI (proxy): false
• Product group name: Indicating measuring devices
• Mounting hole: 3,5
• Length (mm): 15.5 mm
• Dimension H: 7.7 mm
• Dimension h in mm: 7.7 mm
• Dimension d in mm: 3.2 mm
• Measuring contact ball diameter mm: 3.2 mm
• Manufacturing tolerance +/-: 2 m
