Description:

The LF24-MFT US actuator provides 95 of rotation and is provided with a graduated
position indicator showing 0 to 95. The actuator will synchronize the 0 mechanical
stop or the damper or valves mechanical stop and use this point for its zero position
during normal control operations.

Specifications:

Voltage AC/DC: AC/DC24V
Power Consumption (Running): 2.5 W
Power Consumption (Holding): 1 W
Power Consumption For Wire Sizing: 5 VA
Auxiliary Switches:1x SPDT
Torque: 35in-lb [4Nm]
Control Type: MFT/Programmable
Direction Of Motion Motor: selectable with switch 0/1
Direction of Rotation (Fail-Safe): Reversible with cw/ccw mounting
Angle of Rotation: 95
Running Time (Motor): 150s / 90
Running Time range (Motor): 75…300s
Running Time (Fail-safe): <25s
Protection category: IP54
Degree Of Protection NEMA: NEMA2
Enclosure Type: ULEnclosureType2
Ambient Temperature: -22…122F [-30…50C]

Resources:

• BELIMO LF24-MFT-S Spring Return Actuator Technical Literature
• BELIMO LF Series Installation Instructions
