Mitutoyo; Digimatic Interface DMX-1

This D-SUB9 serial interface is a microcontrolled interface for connecting one single measurement device, with Digimatic output, to the RS-232C interface of a computer. It offers you the following benefits:

• Easily connect a measuring device to a computers RS-232C serial port.
• No external power supply is needed, as the small level of power needed is supplied by the handshake lines RTS and DTR.
