142-201 Mitutoyo 30 Mechanical Counter Point Micrometer: 0-25mm

The Mitutoyo142-201Mechanical Counter Point Micrometer has the following specifications:

• Range: 0-25mm
• Graduations: 0.01mm
• Accuracy: +/- .003mm
• Point: 30
• Mass(g): 260g

Features:

• Available in Metric and Inch models
• Points are constructed of hardened steel or carbide depending on the model
• Ratchet mechanism provides an audible click to ensure measurement is being performed at a constant pre-set force
• A spindle lock provides secure locking of the measurement position for easier recording
• Satin chrome finish on the sleeve and laser etched measurements on thimble for easier reading
• Frame is constructed of high-grade steel and has a baked enamel finish for durability
• Supplied in fitted plastic case

The Mitutoyo142-201mechanical counter point micrometer utilizes pointed tips on the anvil and spindle to measure small grooves, keyways and other, difficult-to-reach areas. Available in inch and metric measurements. TheMitutoyo point micrometer with mechanical counterutilizes pointed anvil and spline tips to measure small groves on parts or workpieces along with keyways. A mechanical digit counter displays readings to .001 or .01mm for easier viewing among operators. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements.

Mitutoyo Mechanical Counter Point Micrometers:

• 142-153 Mechanical Counter Point Micrometer: 0-25mm (15)
• 142-201Mechanical Counter Point Micrometer: 0-25mm (30)

• 142-177 Mechanical Counter Point Micrometer: 0-1 (15)
• 142-225Mechanical Counter Point Micrometer: 0-1 (30)
