Elite 450 process gauge was engineered for the oil and gas and industrial process industries. The WGI Elite 450 process gauge was designed with the operators safety in mind. In the event of over-pressuring resulting in a leak, a solid wall separates the rupture forcing the process media through blowing out the back of the gauge.

PLEASE ALLOW ADDITIONAL TIME FOR SHIPMENT OF THIS PRODUCT.CONTACT USVIA PHONE OREMAILTO REQUEST MORE INFORMATION ON AVAILABILITY.

CONTACT USREGARDING INFORMATIONABOUT CANADIAN REGISTRATION NUMBERS, AND MORE QUANTITY BASED DISCOUNTS!

Specifications:

Case Material
Polypropylene safe case solid front with blowout back
Fill Fluid
Silicone
Lens Material
Acrylic
Dial
White aluminum with black and red lettering (UV Resistant Paint)
Pointer
Black aluminum
Accuracy
0.5% Full scale ASME B40.1 Grade 2A
Tube & Socket
316L stainless steel
Temperature Limits
-40C to 60C ambient and medium
Pressure Ranges
-30 Hg. Vacuum to 20,000 psi/kPa
Sizes
4″
