100mm Strip chart recorder with 6 Analog Inputs, CE Approved

BULK ORDERS OR LESS-COMMONPRODUCTS MAY REQUIRE ADDITIONAL TIME FOR SHIPMENT.CONTACT USVIA PHONE OREMAILTO REQUEST MORE INFORMATION ON AVAILABILITY.

The CR06 offers brilliant 6-color printing, Universal temperature & process inputs, Large LED display, less than 6″ panel depth, Nema 4 and RS232 communication as standard.

Features:

• Low Cost 100mm Strip Chart Recorder
• 6 Universal analog inputs
• Easy to Program
• Brilliant 6-color Dot Matrix printing.
• Universal Temperature & Process Inputs
• Large LED display; 18mm/0.71″ High
• Short Depth: 150mm/5.9″
• DIN Panel Cutout: 138mm x 138mm
• IP65/Nema 4X
• RS232 standard
• Optional:
  • 6 relay output
  • 3 digital input
  • RS485 Modbus (includes 6-relay output)
  • 3 relay output & 3 digital input
  • Out of Paper Sensor & Output
  • 2-Year Warranty.pdf

Notes:

• Out-of-paper option requires relay output option or combination relay output / digital input. Relay output #1 is assigned as Out-of-paper output and may also be assigned as an separate process alarm output.
• Field Installed Option: 6 Relay output module
• Not Field Installed Options:
  • Out-of-paper
  • 3 Digital Input
  • 3 Relay / 3 Digital Input

Options:

• Communications:
  • Standard RS-232C
  • RS-485 (includes 6-relay output option)
• Digital Input / Output
  • None
  • 6 Relay outputs
  • 3 Digital Inputs
  • 3 Digital Inputs + 6 relay output
• With or without Out-Of-Paper Sensor

Accessories:

• Chart paper: P/N HZCGA0105EL001 (16M Z-Fold paper 6-pack)
• Ribbon cassette: P/N WPSR188A000001A (6 color: Purple, Red, Green, Blue, Brown, Black)
• RS 485 Module: P/N 910063655A02
• 6 Relay Output Card: P/N 910063655A01

Resources:

• CR06 Strip Chart Recorder Brochure
• CR06 Strip Chart RecorderManual February 2007
• CR06Strip Chart RecorderPrice Page 2018
• FAQ answered from pages of the CR06 Strip Chart Recorder Manual
  • CR06 Communication Manual C0005E
  • CR06 Calibration Procedure
  • CR06 Paper Out Addendum 01-2007
  • CR06 Field Install 6-Relay Card 01-2007
  • CR06 Field Install 6-Relay RS485 & Combo Relay RS485 Cards
  • CR06 Field Replace 6-Relay Card
  • CR06 How to Setup Start/End Printing
  • CR06 How to List Printing
  • CR06 How to Setup Chart Scaling
• CR06 Strip Chart RecorderError Code List
• CR06 Strip Chart RecorderError Code 2 and 10
