The gas pressure switch DG monitors extremely low pressure differentials and triggers switch-on, switch-off or switch-over operations if a set switching point is reached. The switching point is adjustable via a hand wheel.

It monitors positive and negative gas pressures on various industrial gas and air appliances, such as boiler fan monitoring and differential pressure monitoring in firing, ventilation and air-conditioning systems.

MANUAL RESET MODELS:

MFG PART#84447962MODEL:DG10NT.RANGE 0.4-4″W.C. LOW GAS SW. MANUAL RESET, VENTED 8.5 PSI RATED, NON-VENTED 7 PSI RATED, NEMA 4, 120VAC, BLUE LED LIGHT

MFG PART# 84447972MODEL: DG50NT.RANGE 1-20″W.C. LOW GAS SW. MANUAL RESET, VENTED 8.5 PSI RATED, NON-VENTED 7 PSI RATED, NEMA 4, 120VAC, BLUE LED LIGHT

MFG PART# 84447982MODEL: DG150NT. RANGE 12-60″W.C LOW GAS SW, MANUAL RESET, VENTED 8.5 PSI RATED, NON-VENTED 7 PSI RATED, NEMA 4, 120VAC, BLUE LED LIGHT

MFG PART# 84447992MODEL: DG500NT. 120VAC, RANGE 40-200″W.C LOW GAS SW, MANUAL RESET, VENTED 8.5 PSI RATED, NON-VENTED 7 PSI RATED, NEMA 4, 120VAC, BLUE LED LIGHT

See DG Chart here:

Click to Enlarge

ACCESSORIES:

• Bracket for DG Model Pressure Switch
• Conduit Adapter for DG Pressure Switch
• Pilot Lamp Set, Blue for Pressure Switch
• DG Replacement Cover for Manual Reset

RESOURCES:

• DG Pressure Switch Technical Literature
• DG..B and DG..U Pressure Switch Installation instructions
• DG..H, DG..N and DG..I Pressure Switch Installation instructions
• DG..S Pressure Switch Installation instructions
• DG..T Pressure Switch Installation instructions
