This WIKA Bourdon Tube Pressure Gauge is perfect for the process and chemical engineering industry, with its high-quality stainless steel materials and robust design. Measuring liquid and gaseous media in aggressive environments designed to withstand ambient temperature between -40 … + 60C and a permissible medium temperature up to 200 C.

This gauge meets safety standards EN 837-1 and ASME B40.100, featuring a blow-out device with blow-out plug for overpressure protection on the back of the case.

The model 233.50 with stainless steel liquid-filled case is suitable for high dynamic pressure loads and vibrations.

SPECIFICATIONS

MODEL

232.50 / 233.50

NOMINAL SIZE

100mm

SCALE RANGE

-100 … 100,000Kpa

PROCESS CONNECTION

1/2″ NPT

CONNECTOR LOCATION

LOWER MOUNT

MOUNTING FLANGE

POLISHED STAINLESS STEEL

WINDOW

POLYCARBONATE

ACCUARCY CLASS

CLASS 1.6

OVERPRESSURE SAFE

STANDARD

CASE MATERIAL

STAINLESS STEEL

PERMISSIBLE MEDIUM TEMP.

+ 200 C

PERMISSIBLE AMBIENT TEMP.

– 40 … + 60 C

APPLICATIONS

For gaseous and liquid aggressive media that arenot highly viscous or crystallising, also in aggressiveenvironments
Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewatertechnology
Machine building and general plant construction

Only gauges in stock are made available online. If you require a variation not shown in the drop down, please contact us to confirm lead times.
